Remote key programmed successfully. Click “Vehicle Identification Number Programming” to program VIN. Enter VIN number and click “OK”. Now go back to main menu and choose “Measuring Blocks”. Click “Fault Codes and clear all DTC fault codes from ECM, IPC, SDM, BCM and check if all is working. After that OPCOM (OPCOM. Key programming and remote features are also available. The application supports the inspection of a wide range of automotive units and systems, such as the engine, transmission, radio, electronic climate control, engine cooling module, and so on. With OPCOM, you can learn immobilizer keys and remote keys for the central door locking You can reset and program the following immobilizer related items: ECM, BCM, IPC. You will need the vehicle security code found on the CAR-PASS You can reset and program the service interval reminder on the Astra-G, Zafira, Corsa-C, Mervia. How to use OPCOM to program remote central locking. Select PROGRAMMING REMOTE CAR KEY from menu. Now just follow the on screen instructions. Exit the software and disconnect OP COM China clone interface. Open and close door, now try locking your door and then dead lock it. Once you have done this unlocked. I need help with opcom programming, who has a lot of experience working with it and would like to help me? Its for an opel corsa D, remote key learning. Greetz, JanWhat kind of Opcom do you have? Original or clone? CloneIt will be difficult. What firmware number and what software? Do you have a car pass code?

Here I would like to share a guide on how to guide toprogramming a NEW REMOTE CENTRAL LOCKING BOARD to your Astra Mk4 via op com1.59.
You will need the following tools:
2. A key for the vehicle.
Opcom
4. Op com interface and software.
Opcom
Here is the instruction:
1. Put the new remote central locking board into your key.
2. Put the key into the ignition and turn so the battery lightsetc come on, but do not start the car.

4. Start up opcom and click on DIAGNOSTICS.
6. Select model of car.
Opcom remote key programming software
8. Select CENTRAL DOOR LOCKING.
10. Select SECURITY CODE from menu (this should be the only one availableat the time).
12. Select PROGRAMMING REMOTE CAR KEY from menu.
Keyless
14. Click on CLOSE.
15. Exit the software and disconnect OP COM Chinaclone interface.
16. Open and close door, now try locking your door and then deadlock it. Once you have done this unlocked and all should be done.

These things you will need:

A Bosch Remote Key
An OPCOM scanner
A laptop

Remotes you can get from ebay or your local Scrap yard. Transponder Chips are identified on the chip itself, and assuming it is not a programmable one (cloned by a key cutter). OP COM you can get from Chinese sellers. Mine is from obd2diy.fr with free shipment.

Key

Ralink 3070 usb wifi driver. Start programming:

Fire up you computer with OP COM and launch OP COM
Plug in the OP COM and Turn on the Ignition.

From the Main menu select diagnostics (assuming you have used OP COM and configured the settings before)
Automatic does often work, but it's usually slower than just picking the year and Model.

Immobilizer

Select Body Module, then Immobilizer.
Go to Measuring Blocks and you can see what transponder is in use and how many are programmed (You may have 2 keys but only 1 transponder ID, if you've had one Cloned at a Key cutter)
For Immobilizer programming you need to enter the Security Code from your car pass.
You can then go to Special Functions and Erase Transponder Keys. NB: This will erase all keys and may not be necessary if you have all the keys that are programmed.
Once you've erased all Transponders you can turn the ignition off and on again. The EM light will be flashing to show no valid immobilizer signal received.

Now go to Programming. Not sure the difference between Program Transponder Keys new and old, but if new doesn't work tries old.
Now you've programmed a couple of immobilizers, you can view them on the Measuring Blocks option. Soft elicenser download.

Turn the ignition off and on again to check the EM light is not flashing.

Central Locking

If your car has an Alarm then go to Anti Theft Warning, if you don't then go to Central Locking (The programming procedure is the same, but you have additional options with the alarm)
Go to Measuring Blocks, you can see what remote was used last, and the previous one.
Go to Programming, and if necessary Erase Remote Keys (This will erase all remote keys)
Go to Program Remote Key, then click the buttons on the remote you want to add (usually works first click)

Opcom Remote Key Programming Software

If it doesn't work, make sure you have the right type of remote as mentioned at the top of this page.
Program another key if you like, and then you can view them in Measuring Blocks.

Opcom Remote Key Programming Remote

You do not need the security code for Programming the Remotes.

Opcom Remote Key Programming Keyless

Hope this information is useful.
